Smart 2000 Watt Pure Sine Wave Inverter 12 Volt To 110 Volt Dc Ac
Inverter
Product Features:
1, Pure sine wave,strong carrying capacity,wide range of
applications；
2, High conversion efficiency,small no-load current；
3, Soft start for protecting the load；
4, Perfect protection function;
5, Smart fan control,the fan starts to work when the power of load
is more than 30% of rate power.
6, Imported high-quality components,build-in fuse,safe and
reliable；
7, DC input voltage optional:36V,72V,96V,110V；AC output voltage
optional:100v,120V,200V,240V,socket optional.
| Power | 2000W | 2000W | 2000W | 2000W | 2000W | 2000W |
| Peak power | 4000W(5ms) |
| Input voltage | 12V | 24V | 48V | 12V | 24V | 48V |
| Output voltage | 110VAC±10% | 220VAC±5% |
| No-load current | ＜1.7A(DC13V) | ＜1.05A(DC26V) | ＜0.85A(DC52V) | ＜1.7A(DC13V) | ＜1.05A(DC26V) | ＜0.85A(DC52V) |
| Output frequency | 50HZ±1%/60HZ±1% |
| Output waveform | Pure sine wave |
| Output harmonic content | THD＜3% |
| Output efficiency | ＞86%(DC13V) | ＞88%(DC26V) | ＞90%(DC52V) | ＞86%(DC13V) | ＞88%(DC26V) | ＞90%(DC52V) |
| Input voltage range | 11V～15V | 22V～30V | 44V～60V | 11V～15V | 22V～30V | 44V～60V |
| Low voltage alarm | 10.5±0.3V | 21±0.6V | 41.8±1.2V | 10.5±0.3V | 21±0.6V | 41.8±1.2V |
| Low voltage shutdown | 9.5±0.2V | 19±0.3V | 38±0.4V | 9.5±0.2V | 19±0.3V | 38±0.4V |
| Over voltage shutdown | 16±0.5V | 31±1V | 65±2V | 16±0.5V | 31±1V | 65±2V |
| Low voltage recovery | 11.8±0.3V | 23.6±0.4V | 47.2±0.8V | 11.8±0.3V | 23.6±0.4V | 47.2±0.8V |
| Over voltage recoverty | 15.7±0.3V | 31.8±0.4V | 63±1V | 15.7±0.3V | 31.8±0.4V | 63±1V |
| Overload shutdown | 120%～125% |
| Protecting function description | Low voltage: Red LED turn on,buzzer alarm,auto recovery |
| Over voltage:Red LED turn on,auto recovery |
| Overload:Red LED turn on,auto shutdown, restart by hand |
| Over temperature:Red LED turn on,buzzer alarm,auto recovery |
| Short circuit:auto recovery |
| Reverse connection of the battery terminal:blown fuse |
| Operating temperature | –10℃ +40℃ |
| Storage temperature | –30℃+70℃ |
| Relative humidity | 20%～90%RH No condensation |
| Operating height | ≦3000m |
| shape size | 444*199*73mm |
| Net weight | 5.66±0.05kg | 5.54±0.03kg | 5.46±0.03kg | 5.66±0.05kg | 5.54±0.03kg | 5.46±0.03kg |
| Packing size | 480*240*140mm |
| Gross weight | 7.16±0.05KG | 6.88±0.05KG | 6.8±0.05KG | 7.16±0.05KG | 6.88±0.05KG | 6.8±0.05KG |
Certificate of Design Patent:
General FAQ-1
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: What certificate do you have?
A: We have CE,ROHS.
3.Q:What kind of payment do you accept?
A:We accept T/T,Paypal,Escrow,Western Union for sample order,
T/T,LC for bulk order.
4.Q:Do you have any MOQ?
A:we don’t have MOQ for neutral package, but if you want to to
print you brand logo on the product, then the MOQ is 200pcs.
5. Q: How does your factory do regarding quality control?
A: We have a special QC department in charge of products’ quality.
6. Q: How long is the warranty period?
A: All of our inverter and controller products have two years
warranty.
